Author: William Krantz, MD, West Virginia University School of Medicine, Department of Radiology
Editor: Matthew Tews, DO, MS, Medical College of Wisconsin, Department of Emergency Medicine


At the end of this chapter, the student will be able to:

  • Identify details to verify when looking at radiologic imaging
  • Assess adequacy of chest radiographs
  • Develop a systematic approach to reading chest radiographs
  • Identify important signs to know when reading chest radiographs
  • Understand the importance of knowing common diagnoses on the chest radiograph


Section 1: Verify Details

Although mistakes are rare, they do occur and you should verify details pertaining to your patient on every study you review.

  • Patient – Ensure the study was performed on the correct patient.
  • Time and date – Note the time and date of the study.  This is especially important if there are comparison studies.  By convention, the older study is displayed on the left, though this is not always the case.
  • Study type – Verify the type of study performed.  Sometimes a study will be changed depending on what the patient can tolerate.  For example an AP supine CXR may be done on a patient that can’t stand for a PA/lat CXR.
  • Comparisons – Make sure you view every image submitted. It is not uncommon for multiple views to be taken for an AP supine CXR study on a difficult to position patient. Compare these to previous studies, if available.


Section 2: Assess Adequacy

PA/lateral projection is the standard used for most patients who are ambulatory and able to stand.  In this view, the mediastinum should have a normal width and a good inspiratory effort should results in full diaphragm expansion.


PA Projection – Normal Mediastinum and Good Inspiratory Effort

AP projection is obtained with the patient in bed and lying flat or partly upright.  It is usually reserved for non-ambulatory patients.  AP projections have the disadvantage of making the heart an mediastinum appear more prominent as well as usually resulting in shallower inspiration which can limit evaluation of the lung bases.  A lateral projection is not obtained with a AP projection, thereby limiting the view of the chest further.


AP Projection – Widened Mediastinum and Less Inspiratory Effort

It is therefore preferable to order a PA/lateral CXR over an AP view when possible.


It is not uncommon, especially for AP supine CXRs, for the patient to be slightly rotated. Rotation can be assessed by measuring the distance between the medial edges of the clavicles to the vertebral spinous processes.  They should be equal or near equal. Anterior structures move the same direction as rotation so the clavicle/spinous process width is increased on the side to which the patient is rotated. This patient is rotated to the left.


Red Dotted Line = Slight Rotation to the Left

Here is a patient severely rotated to the left. Severe rotation can alter the normal cardiomedistinal contour and make interpretation difficult.


Significant Rotation to the Left


Deeper inspirations show more lung and result in better overall images with less haziness at the lung bases and less enlargement of the heart and mediastinum. A good inspiration on a PA CXR shows at least 9 posterior ribs.

The following films were of the same patient and taken using the same AP projection.  The image on the left is a poor inspiratory  effort (ribs 1-6), while in the film on the right, the patient achieved a much deeper inspiration on the bottom xray (ribs 1-10).


Poor Inspiratory Effort                                                   Good Inspiratory Effort


Under-penetration results from not enough xrays passing thru to allow differentiation of dense structures, thus the mediastinum and spine appear white. In an over-penetrated CXR too many xrays have passed thru the chest preventing differentiation of low density structures, thus the lung fields appear black. With proper penetration, the spine should be faintly visible behind the heart.


Under-penetrated                                                                Over-penetrated                                                             Correctly-penetrated

Section 3: Develop Systematic Approach

It is important to develop a system for looking at imaging and be consistent in its use.  Different systems exist, whether it is based on anatomical structure (looking at one structure, then another, and so on) or scanning the image in a pattern (back and forth from top to bottom).  No system is best. What is important is finding one that you like and using it consistently. Resist the natural tendency to focus in on the area which first catches your eye otherwise you may miss the more important subtle finding.


The ABCDs approach is taught as an aid for remembering steps in many different learning environments.  It can be applied in interpreting chest xrays too. The mneumonic starts with A and can go through H.

A – AirwayE – Effusion
B – BonesF – Fields
C – CardiacG – Gastric
D – DiaphragmH – Hila

A – Airway

  • Identify trachea and note if it is midline and straight. A deviated trachea can be caused by many etiologies including rotation and masses.
  • Identify carina and estimate the angle.  Normally 60-100°. Common things that may increase this angle include left atrial enlargement and adenopathy.
  • Trace out right and left mainstem bronchi.


Trachea midline: yellow; Spinous process and medial clavicles: red. This patient is slightly rotated right.


Leftward tracheal deviation due to large substernal goiter

Endotracheal tubes

Endotracheal tube (ETT) tip should sit 3-5cm above the carina. The ETT can be too high above the carina and will need to be advanced, or too deep into the right mainstem and need to be pulled back.


Intubation with Good Position of ETT

Red = ETT; Yellow = Trachea and Bronchi


Right mainstem bronchus intubation

B – Bones

Evaluate clavicles, AC joints, GH joints and humeri followed by the ribs and vertebra.


Normal Alignment of Clavicle, Glenohumeral Joint and Proximal Humerus on a PA View of Chest



Subtle Anterior Shoulder Dislocation.

The humeral head (solid yellow line) is out of the glenoid fossa (dotted yellow line)

Sometimes, overlying structures on the radiograph can obscure positive findings.  If there is suspicion of an injury or abnormality in the region of overlying structures (such as cords, belts, jewelry), remove them and repeat the radiograph.


“Normal” Chest Radiograph at First Glance

However, cardiac monitor cords overly the distal clavicle


Distal Clavicle Fracture

The film shows a distal clavicle fracture when the monitor cord is removed

Rib fractures can sometimes be extremely subtle.  Be sure to trace all the ribs to identify step offs.


Left Sided Upper Rib Fractures

A useful trick can be to flip the image upside down or sideways which makes the ribs appear to stand out.


Left Sided Rib Fractures

Visualize the entire spine and look for vertebral body height loss and alignment


L1 Compression Fracture = Red; T11 and T12 Normal Body Height (Yellow)

C – Cardiac

Next, check the cardiac size: normal is <50% of thoracic diameter on PA projection and <55% on AP projection.


Normal Cardiac Size on PA CXR

Red = thoracic diameter; Yellow = cardiac diameter

Verify cardiac borders are sharp and defined.

Evaluate aorta and AP window (should be concave)



Normal AP Window and Cardiac Border

Red = Aortic contour; Blue = Upper cardiac border; Yellow = AP window

D – Diaphragm

Verify diaphragm and costophrenic angles are sharp and well defined.


Sharp Diaphragmatic Angles = Yellow

Note any flattening of diaphragm which may indicate hyperexpanded lungs such as seen in a patient with COPD.


Flattened Diaphragm in COPD = Yellow

Obscuration of all or a portion may indicate pleural effusion or consolidation.


Left Sided Pleural Effusion

Look for free air under diaphragm on upright projections.


Free Air Under Diaphragm = Yellow

E – Effusion

Look for ‘blunting’ of the costophrenic angles on PA projection and posterior costophrenic sulcus on lateral projection. As much as 300-500cc of fluid may not be seen on PA projection, but seen on lateral projection.


Pleural Effusion on Lateral View

Fluid may track into right minor fissure causing it to thicken or even form a pseudotumor.


Right Minor Fissure Fluid

Loculated effusion may present as nondependent pleural thickening.


Right Sided Loculated Effusion

F – Fields

Lung fields should generally be uniformly dark grey.


Uniformly Dark Grey Lung Fields

Increased density may be due to airspace disease such as pneumonia, masses, pleural effusions, pulmonary edema, or atelectasis


Left Lower Lung with Effusion

Decreased density may be due to pneumothorax or hyperexpansion due to COPD.


Left Sided Pneumothorax with Tension Component

Heart is being pushed to the right

There are several other findings to look for with the lung fields.  Sometimes they are obvious and take over most of the view of the lung fields and other times they are subtle and scattered or singular.


‘Bat-wing’ Pulmonary Edema


Septic Emboli

G – Gastric

Look for gastric air bubble located in LUQ below the left hemidiaphragm and cardiac silhouette.

Hiatal hernias are very common. Usually seen as a rounded density at the midline behind the heart.

Sometimes an air-fluid level may be seen.


Diaphragmatic Hernia


Kartagener’s Disease (dextrocardia, airspace disease, situs inversus)


A case that at first glance appears to represent massive cardiomegaly, but closer inspection of the lateral view reveals air density anteriorly that resembles air in the bowel.  Finding was suspicious for hernia.


Coronal CT image reveals mesenteric fat and bowel in a large diaphragmatic hernia.

H – Hila

Locate right and left main pulmonary arteries.

Note any obvious contour abnormalities which may indicate masses or adenopathy.


Normal Pulmonary Artery Contour

Section 4: Learn Important Signs

Silhouette Sign

Normally on Xray studies, two adjacent structures are visually distinct from one another because they have different densities. Thus you can see a silhouette of the dense structure against the adjacent less dense structure, for example the cardiac silhouette or diaphragms adjacent to the air containing lungs.


Normal Cardiac Silhouette

If something alters the tissue density, typically the less dense lung becoming more dense due to mass or consolidation, the silhouette may be lost because the adjacent structures are now closer in density.


Left Sided Effusion Causing Loss of Cardiac Silhouette

The classic example is a right middle lobe (RML) consolidation. Normally, the right heart border silhouette is seen because it is next to air containing lung. In the presence of a RML consolidation which replaces air with denser inflammatory material, the right heart silhouette is lost.


Normal Right Heart Border                         Loss of Right Heart Border from RML Infiltrate

A right lower lobe consolidation will not result in loss of right heart silhouette because they are not adjacent to each other.


RLL Consolidation – No Loss of Right Heart Border

Sometimes it is not obvious on the PA view which side a consolidation is on because it may be located in the posterior sulcus and therefore obscured.

We can use the lateral view and an understanding of the silhouette sign to help determine when a consolidation is present and which side it is on.


“Normal” View of PA and Lateral Chest

Notice how on this normal lateral the diaphragms extend all the way from anterior to posterior. The right diaphragm usually is slightly higher than the left and the left often will not extend fully anterior because of the heart being adjacent to it.

Now notice how the left diaphragm silhouette no longer extends posteriorly all the way. This is because it has lost its silhouette because there is a dense consolidation directly adjacent to it.


Loss of Left Diaphragm Due to Consolidation

Air Bronchogram

Normally bronchioles are not visible because they are surrounded by air in adjacent alveoli

In the setting of air in the alveoli being displaced by fluid or cellular debris, the air in the bronchioles appears as a translucent tube against the hazy opacity of the affected airspaces.

This can be a clue that a opacity may be due to airspace consolidation and not mass.


Air bronchogram sign (enlarged right lower lobe image on right)

Deep Sulcus Sign

In patients who are upright when imaged, such as for a PA/lateral CXR, air in the pleural space from a pneumothorax tends to collect in non-dependent locations, such as the apices.


Left Apical Pneumothorax

In patients who are supine, air may collect at the bases and anterior chest, potentially resulting in a deep sulcus sign, which indicates a pneumothorax.


Deep Sulcus on Right (Yellow Arrows) on Supine Radiograph

Continuous Diaphragm Sign

Normally, the central portion of the diaphragm is not visible because it is contiguous with the cardiac silhouette.


“Normal” Appearance of the Right and Left Diaphragms

If it is visible then it is highly suggestive of free air in the mediastinum or peritoneal cavity.


Continuous Diaphragm from Intraperitoneal Free Air

(Dotted yellow line outlines mediastinal air)
